Water-Cooled Handheld Laser Welding Machine
1500W–3000W
A handheld fiber laser welder with an intelligent dual-temperature chiller — built for production lines that weld all shift long, with laser cleaning on the same machine for pre-weld rust removal and post-weld seam finishing.
- Long-term Stability — Cost reduction & efficiency
- Freedom of Control — Unlimited pathing
- Zero Pollution — Zero defects
Why this machine
Cost reduction & efficiency
Smart temperature control ensures 8 hours of continuous welding without overheating. Optimized for production lines and customized manufacturing with 24/7 non-stop operation, the HW Series lowers total cost per seam while keeping output steady from the first part of the shift to the last.
- Dual-temperature, dual-control chiller cools laser source and torch separately
- No power derating in hot workshops (5–40°C operating range)
- Alarm and auto-protection on water flow and temperature
Unlimited pathing
A flexible handheld torch makes laser welding effortless on complex trajectories — inside corners, curved seams, large or awkward workpieces that a fixed welding station can't reach. Simple to operate with superior seam aesthetics, it is easy for beginners to master quickly.
- Lightweight ergonomic torch with long fiber cable
- Preset process library for common materials and thicknesses
- New operators productive after a short training session
Zero defects
Smoke-free and spatter-free. Smooth, flat seams with no welding scars eliminate secondary grinding — cleaner for the shop floor and far easier on quality control. Switch to the cleaning nozzle to strip rust, oil and heat tint without chemicals or abrasives.
- Narrow heat-affected zone, minimal deformation on thin sheet
- Little or no post-weld grinding and polishing
- Weld, clean and seam-finish on one machine
Technical Parameters
- Power
- 1500W
- Equipment Size
- 950×660×930mm
- Weld Seam Requirement
- ≤0.5mm
- Welding Speed
- 0–120mm/s
- Cooling Method
- Dual-temperature, dual-control intelligent chiller
- Operating Temperature
- 5–40°C
- Power
- 2000W
- Equipment Size
- 950×660×930mm
- Weld Seam Requirement
- ≤0.5mm
- Welding Speed
- 0–120mm/s
- Cooling Method
- Dual-temperature, dual-control intelligent chiller
- Operating Temperature
- 5–40°C
- Power
- 3000W
- Equipment Size
- 1100×660×970mm
- Weld Seam Requirement
- ≤0.5mm
- Welding Speed
- 0–120mm/s
- Cooling Method
- Dual-temperature, dual-control intelligent chiller
- Operating Temperature
- 5–40°C
Need a different format or power level? Ask us — configurations can be matched to your material and output.
Welding Capability by Material
Typical maximum single-pass weld penetration for butt joints. Use this as a starting point when choosing a power level.
| Material | 1500W | 2000W | 3000W |
|---|---|---|---|
| Stainless Steel | 3mm | 4mm | 6mm |
| Carbon Steel | 3mm | 4mm | 6mm |
| Aluminum Alloy | 2mm | 3mm | 4mm |
| Galvanized Sheet | 2.5mm | 3mm | 4mm |
| Brass / Copper | 1.5mm | 2mm | 3mm |
Reference values — actual penetration depends on joint design, shielding gas and wire feed. Send us your parts and we will run weld samples. Request a sample test
Built on industrial-grade parts
Fiber Laser Source
Industrial-grade continuous fiber laser with high electro-optical efficiency and long service life.
Handheld Welding Torch
Wobble-beam torch with swappable welding and cleaning nozzles and a contact-safety interlock.
Dual-Circuit Chiller
Separate temperature control for laser source and optics keeps output stable across a full shift.
Touchscreen Controller
Stores process parameters per material and thickness; multi-language interface.
Where the HW Series is used
Kitchenware & Sinks
Stainless cabinets, sinks and catering equipment with clean seams that need no polishing.
Sheet Metal Enclosures
Electrical cabinets, chassis and boxes — fast corner and edge welds on thin sheet.
Metal Furniture & Doors
Stainless doors, railings and furniture frames with minimal distortion.
Automotive Parts
Brackets, exhaust components and battery housings in steel and aluminum.
Signage & Decoration
Channel letters and decorative metalwork where seam appearance matters.
Surface Cleaning
Rust, paint and oxide removal before welding, and heat-tint removal after.
HW Series questions
Handheld laser welding uses a focused laser beam, delivered through a fiber-optic cable to a handheld torch, to melt and join metal. It's faster to learn than TIG welding and produces a smaller heat-affected zone.
A water chiller holds the laser source and torch at a stable temperature, so the machine can weld for a full shift — up to 8 hours continuously — without derating or overheating. That matters most at 1500W and above and in hot workshops.
Yes. Swapping to the cleaning nozzle turns the machine into a laser cleaner for removing rust, oil, paint and post-weld discoloration — no chemicals or abrasive media.
1500W covers most stainless and carbon steel sheet up to about 3mm. Choose 2000W for thicker steel or regular aluminum work, and 3000W for 4–6mm steel or high-volume production. See the capability table above, or send us your part drawings.
Yes, with proper PPE (laser safety goggles and protective clothing) and standard shop safety practices. The torch requires workpiece contact to fire, reducing the risk of accidental exposure.
Yes — installation guidance, operator training and ongoing technical support are included with every machine.
Request a Quote
Tell us your material, thickness and output — a sales engineer will reply within 24 hours with a configuration and price.
